THE PROPHET DIGITAL DELAY features
- Studio quality digital delay pedal
- Up to 1300 ms delay time
- True Bypass for signal integrity
- Built-like-a-tank metal chassis
- Runs on 9 V battery or the TC Electronic Powerplug 9 (not included)
Technical facts
Specifications
- Headroom (Max. Input Level)
- +2dB
- In
- >350KΩ
- Out
- 1KΩ
- Noise floor
- -72dB
- Frequency range
- 20-11.5KHz
- Latency
- Y Max:3/8 hour
- Min & max delay time
- 27,125ms - 1302ms
- Delay range offered through the 3-position switch
- 16th note: 27,125ms - 217ms 8th note: 54,25ms - 434ms Dotted 8th: 162,75ms - 1302ms
